C80 stencil printer
C80 continuity investigation · Build 9.2 · loading
Loading printer app… If this message remains, the app files did not load. Reload the HTTPS page.
No transfer
Physical calibration and official-app handoff
Load the pattern, then Print. Measure A–B and A–C between line centres using a millimetre ruler. Both target 100 mm. Keep the same printer and paper settings. Do not calibrate a sheet with gaps.
Calibration lasts for this session. Verify with a fresh pattern. The 1600-dot command width is retained; actual printhead width remains unverified.
For the official Windows or iOS app: import the saved image and set its physical size there. This handoff does not automate printing or prove its timing.
Connection and performance diagnostics
Fixed 512-byte acknowledged writes.
No connection inspected yet.
Per-write latency and throughput will be measured while printing.
One reference strategy: 512-byte acknowledged writes, one in flight. Continuous physical printing and 30–60 second completion remain unverified. Transfer progress is not printer completion.
